Apple Partition Map (APM) is a partition scheme used to define the low-level organization of data on disks formatted for use with 68k and PowerPCMacintosh computers. It was introduced with the Macintosh II.^[1]

Disks using the Apple Partition Map are divided into logical blocks, with 512 bytes usually belonging to each block. The first block, Block 0, contains an Apple-specific data structure called “Driver Descriptor Map” for the Macintosh Toolbox ROM to load driver updates and patches before loading from a MFS or HFS partition.^[2] Because APM allows 32 bits worth of logical blocks, the historical size of an APM formatted disk using small blocks^[3] is limited to 2 TiB.^[4]

The Apple Partition Map maps out all space used (including the map) and unused (free space) on disk, unlike the minimal x86 master boot record that only accounts for used non-map partitions. This means that every block on the disk (with the exception of the first block, Block 0) belongs to a partition.

Some hybrid disks contain both an ISO 9660 primary volume descriptor and an Apple Partition Map, thus allowing the disc to work on different types of computers, including Apple systems.

Intel-based Macs[edit]

For accessing volumes, both APM and GUID partitions can be used in a standard manner with Mac OS X Tiger (10.4) and higher. For starting an operating system, PowerPC-based systems can only boot from APM disks^[5] whereas Intel-based systems generally boot from GUID disks.^[1][6][7] Nevertheless, Intel-based Macs are able to boot from APM, GPT (GUID Partition Table) and MBR (Master Boot Record, using the BIOS-Emulation called EFI-CSM i.e. the Compatibility Support Module provided by EFI).

Intel-based models that came with Mac OS X Tiger (10.4) or Leopard (10.5) preinstalled had to be able to boot from both APM and GUID disks due to the installation media for these universal versions of Mac OS X, which are APM partitioned in order to remain compatible with PowerPC-based systems.^[8] However, the installation of OS X on an Intel-based Mac demands a GUID partitioned disk or will refuse to continue, the same way installation on a PowerPC-based system will demand an APM partitioned destination volume. Cloning an already installed OS X to an APM partition on Intel systems will remain bootable even on 2011 Intel-based Macs. Despite this apparent APM support, Apple never officially supported booting from an internal APM disk on an Intel-based system. The one exception for a universal version of Mac OS X (Tiger or Leopard) is an official Apple document describing how to set up a dual bootable external APM disk for use with PowerPC and Intel.^[9]

Layout[edit]

Each entry of the partition table is the size of one data block, which is normally 512 bytes.^[1][10] Each partition entry on the table is the size of one block or sector of data. Because the partition table itself is also a partition, the size of this first partition limits the number of entries to the partition table itself.

The normal case is that 64 sectors (64 × 512 = 32 KB) are used by the Apple Partition Map: one block for the Driver Descriptor Map as Block 0, one block for the partition table itself and 62 blocks for a maximum of 62 data partitions.^[11]

Each partition entry includes the starting sector and the size, but also a name, a type, a position of the data area and possible boot code. It also includes the total number of partitions in that partition table.^[12] This ensures that, after reading the first partition table entry, the firmware is aware of how many blocks more to read from the media in order to have processed every partition table entry. All entries are in big-endian byte-order.^{[citation needed]}

Partition identifiers[edit]

Types beginning with 'Apple_' are reserved for assignment by Apple, all other custom defined types are free to use. However registrationwith Apple is encouraged.

Partition status[edit]

Partition status is a bit field composed of the flags:

See also[edit]

• Amiga rigid disk block (RDB)
• Extended boot record (EBR)
• GUID Partition Table (GPT)
• Host protected area (HPA)
• Master boot record (MBR)

References[edit]

1. ^ ^abc'Technical Note TN2166 – Secrets of the GPT'. Apple. Retrieved 2013-02-24. …a standard block size of 512 bytes… […] Apple did consider extending APM to support larger disks. However, as such a change would break all existing partitioning tools…
2. ^Mac OS: Technical overview of disk volume structures
3. ^Apple Support Communities: Guid Partition or Apple Partition? (2012)
4. ^MacTech Magazine: Apple's Transition from Apple Partition Map to the GUID Partition Table by Criss Myers
5. ^Apple Mailing List: Subject: Re: Apple Partition Scheme or GUID Partition SchemeArchived 2009-04-06 at the Wayback Machine, Timothy Standing, 2006-04-30
6. ^Apple Support Communities: Create a bootable clone using Disk Utility (2014): an example of problems trying to boot on an Intel Mac using an APM partitioned drive.
7. ^Apple Support Communities: Running Mavericks + FCPX on External Boot Drive? (2014): OS X Mavericks does not boot from APM partitioned drives.
8. ^OWC: Booting your Intel Mac to an APM-formatted drive, M. Christopher Stevens
9. ^Mac OS X 10.5: Creating and maintaining a bootable 'universal' external disk
10. ^Rebe, René; Klaus, Susanne (2007). 'Creating custom Linux solutions – Apple Partition Map'. T2 System Development Environment. While the original intent was to handle various block sizes, in practice only 512 byte blocks are supported.
11. ^'Yellow Dog Solutions – Attaching Firewire Disks to a Linux Box'. Fixstars Corporation. Archived from the original on 2009-10-13. Retrieved 2013-02-24. Comment: The command pdisk -l /dev/sda shows a size of 63 blocks for the Apple_partition_map. There is a multitude of examples like this to be found on the internet.
12. ^'IOApplePartitionScheme.h'. Apple. 2009. Retrieved 2016-08-07.

External links[edit]

• Mac OS: Technical overview of disk volume structures Overview of the elements of a disk volume / partition
• File System Forensic Analysis: PC-based Partitions – Apple partitions Detailed technical analysis of the structure of Apple's partition map.

This article provides a list of frequently asked questions about the GUID Partition Table disk architecture.

Original product version: Windows Server 2012 R2
Original KB number: 302873

Important

This section, method, or task contains steps that tell you how to modify the registry. However, serious problems might occur if you modify the registry incorrectly. Therefore, make sure that you follow these steps carefully. For added protection, back up the registry before you modify it. Then, you can restore the registry if a problem occurs. For more information about how to back up and restore the registry, see How to back up and restore the registry in Windows.

What is a GUID Partition Table disk

The GUID Partition Table disk architecture was introduced as part of the Extensible Firmware Interface initiative. GUID Partition Table is a new disk architecture that expands on the older Master Boot Record (MBR) partitioning scheme that has been common to Intel-based computers.

A partition is a contiguous space of storage on a physical or logical disk that functions as though it were a physically separate disk. Partitions are visible to the system firmware and the installed operating systems. Access to a partition is controlled by the system firmware and the operating system that is currently active.

Why do we need GUID Partition Table

GUID Partition Table disks can grow to a large size. As of July 2001, the Microsoft implementation supports a hard disk of up to 18 EB (512 KB LBAs).

The number of partitions on a GUID Partition Table disk is not constrained by temporary schemes such as container partitions as defined by the MBR Extended Boot Record. The Microsoft implementation of GUID Partition Table is limited to 128 partitions. However, it is important to note that one partition is used for the EFI System Partition, one for the Microsoft Reserved and two more are used if you use dynamic disks. This leaves 124 partitions for data use.

The GUID Partition Table disk partition format is well defined and fully self-identifying. Data that is critical to the operating system is located in partitions and not in unpartitioned or hidden sectors. GUID Partition Table does not allow for hidden sectors or partitions. GUID Partition Table disks use primary and backup partition tables for redundancy and CRC32 fields for improved partition data structure integrity. The GUID Partition Table partition format uses version number and size fields for future expansion.

Each GUID Partition Table partition has a unique identification GUID and a partition content type, so no coordination is necessary to prevent partition identifier collision. Each GUID Partition Table partition has a 36-character Unicode name, which means that any software can present an easily readable name for the partition without any additional understanding of the partition.

What is wrong with MBR partitioning

MBR disks support only four primary partitions table entries or multiple logical partitions in the extended partition. If more partitions are wanted, a secondary structure, an extended partition, is necessary. Extended partitions are then subdivided into one or more logical disks.

Only one extended partition can be present on any given drive, and the maximum number of logical drives is MAXULONG/4. All MBR disk partitions and logical drives must be cylinder-aligned, even on hardware RAID sets that are built from multiple different drives with no clear underlying physical geometry.

MBR partitioning rules are complex and poorly specified. For example, does cylinder alignment mean that each partition must be at least one cylinder in length? An MBR partition is identified by a two-byte field, and coordination is necessary to avoid collision. IBM originally provided that coordination, but as of July 2001, there is no single authoritative list of partition identifiers.

Another common practice is to use partitioned or 'hidden' sectors to hold specific information. That practice is undocumented and results in severe system problems that are difficult to debug. Over the years, broken implementations and tools have been released to the public, making support difficult.

Where can I find the specification for GUID Partition Table disk partitioning

Chapter 16 of the Extensible Firmware Interface specification defines the GUID Partition Table format. This document is available at the following Intel Web site:

Third-party information disclaimer

The third-party products that this article discusses are manufactured by companies that are independent of Microsoft. Microsoft makes no warranty, implied or otherwise, about the performance or reliability of these products.

Is Extensible Firmware Interface required for a GUID Partition Table disk

No. GUID Partition Table disks are self-identifying. All the information that is needed to interpret the partitioning scheme of a GUID Partition Table disk is completely contained in structures in specified locations on the physical media.

How big can a GUID Partition Table disk be

In theory, a GUID Partition Table disk can be up to 264 sectors in a single logical block in length. Logical blocks are commonly 512 bytes or one sector in size.

In practice, Windows XP supports GUID Partition Table disks of up to approximately 18 exabytes in size.

How many partitions can a GUID Partition Table disk have

In theory, an unlimited number. As the July 2001, the Microsoft implementation is 128 partitions. The number of partitions is limited by the amount of space that is reserved for making partition entries.

Can a disk be both a GUID Partition Table disk and an MBR disk

No. However, all GUID Partition Table disks contain a protective MBR that is used for legacy programs that do not understand the GUID Partition Table disk structure.

What is a Protective MBR

The Protective MBR, beginning in sector 0, precedes the GUID Partition Table partition table on the disk. The MBR contains one type 0xEE partition that spans the entire length of the disk. This is the same regardless of the number of partitions that are defined in the GUID Partition Table disk entry array.

Why does the GUID Partition Table have a Protective MBR

The Protective MBR protects GUID Partition Table disks from previously-released MBR disk tools such as Microsoft MS-DOS FDISK or Microsoft Windows NT Disk Administrator. These tools are not aware of GUID Partition Table and do not know how to properly access a GUID Partition Table disk. Legacy software that does not know about GUID Partition Table interprets only the Protected MBR when it accesses a GUID Partition Table disk. These tools will view a GUID Partition Table disk as having a single encompassing (possibly unrecognized) partition by interpreting the Protected MBR, rather than mistaking the disk for one that is unpartitioned.

Why would a GUID Partition Table-partitioned disk appear to have an MBR on it

If this occurred, you must have used an MBR-only-aware disk tool to access the GUID Partition Table disk.

If the disk is larger than the maximum size an MBR can report, will the entire disk contents be protected

The EE partition in the Protective MBR is specified to be the maximum size that is allowable in an MBR.

Can Windows read, write, and boot from GUID Partition Table disks

• Can the 64-bit version of Windows XP read, write, and boot from GUID Partition Table disks?

  Yes.

• Can the 64-bit version of Windows XP read, write, and boot from MBR disks?

  The 64-bit version of Windows XP can read and write MBR disks, but cannot boot from MBR disks.

• Can the 32-bit version of Windows XP read, write, and boot from GUID Partition Table disks?

  No. The 32-bit version will see only the Protective MBR. The EE partition will not be mounted or otherwise exposed to program software.

• Can the 32-bit version of Windows XP read, write, and boot from MBR disks?

  Yes.

• Can Microsoft Windows 2000, Microsoft Windows NT 4.0, or Microsoft Windows 98/95 read, write, and boot from GUID Partition Table?

  No. Legacy software will see only the Protective MBR.

What about mixing and matching GUID Partition Table and MBR disks on the same computer

GUID Partition Table and MBR disks can be mixed only on 64-bit systems, and the following restrictions apply:

• The Windows XP loader and the boot partition must reside on a GUID Partition Table disk. Other hard disks can be either MBR or GUID Partition Table.

• Both MBR and GUID Partition Table disks can be present in a single dynamic disk group. Volume sets can span both MBR and GUID Partition Table disks, however, the MBR cylinder alignment restriction might cause some difficulties with mirroring or striping MBR and GUID Partition Table disks.

What about removable media

Removable media must be MBR or superfloppy.

What is a superfloppy

Removable media without either GUID Partition Table or MBR formatting is considered a superfloppy. The entire media is treated as a single partition.

The media manufacturer performs any MBR partitioning of removable media; Windows never partitions removable media. If the media does have an MBR, only one partition is supported. There is little user-discernible difference between MBR-partitioned media and superfloppies.

Examples of removable media include floppy disk drives, JAZZ disk cartridges, magneto-optical media, DVD-ROM, and CD-ROM. Hard disk drives on external buses such as SCSI or IEEE 1394 are not considered removable.

What is the default behavior of Windows when partitioning media

• What is the default behavior of the 64-bit version of Windows XP when partitioning media?

  Fixed disks are partitioned by using GUID Partition Table partitioning. GUID Partition Table disks can be converted to MBR disks only if all existing partitioning is first deleted, with associated loss of data.

• What is the default behavior of the 32-bit version of Windows XP when partitioning media?

  Only MBR disks can be used. MBR disks cannot be converted to GUID Partition Table disks.

Extensible Firmware Interface Firmware

• How can a drive letter in the operating system be mapped to a partition in Extensible Firmware Interface Firmware?

  There is no inherent mapping between drive letter and partition that can be used to determine one from the other. A basic data partition must be identified by its partition GUID.

• How can an Extensible Firmware Interface System Partition be created?

  Extensible Firmware Interface System Partitions can be created by using the Extensible Firmware Interface firmware utility Diskpart.efi or the Windows XP command-line utility Diskpart.exe, or they can be created programmatically by using IOCTL_SET_DRIVE_LAYOUT .

What can be changed on a partition

You should not change any partition header entry directly. Do not use disk tools or utilities to make alterations or changes.

What partitioning does Windows XP support on detachable disks

Detachable disks are commonly expected to migrate between computers or simply to be unavailable to the operating system at times. Examples of detachable disks are IEEE 1394 disks, which can be easily disconnected by the end user, or Microsoft Cluster Services (MSCS) shared disks, which move between nodes in a cluster. Windows XP supports only MBR partitioning on detachable disks.

Extensible Firmware Interface System Partition

• What is the Extensible Firmware Interface System Partition?

  The Extensible Firmware Interface System Partition contains the NTLDR, Boot.ini, and other files that are necessary to boot the computer, such as drivers. The Partition GUID defines the Extensible Firmware Interface System Partition:

  DEFINE_GUID (PARTITION_SYSTEM_GUID, 0xC12A7328L, 0xF81F, 0x11D2, 0xBA, 0x4B, 0x00, 0xA0, 0xC9, 0x3E, 0xC9, 0x3B)

• Do only GUID Partition Table disks have Extensible Firmware Interface System Partitions?

  No, MBR disks can also have Extensible Firmware Interface System Partitions. Extensible Firmware Interface specifies booting from either GUID Partition Table or MBR. The Extensible Firmware Interface System Partitions on an MBR disk is identified by partition type 0xEF. However, Windows XP does not support booting Extensible Firmware Interface from MBR disks or 0xEF partitions.

• How big is the Extensible Firmware Interface System Partition?

  The Extensible Firmware Interface System Partition is determined by using the following algorithm:

  Max (100MB, min (1 percent of physical disk, 1GB))

  In other words, the size of the Extensible Firmware Interface System Partition must be the larger of these two numbers, 100 MB or 1 percent of the physical disk size (up to 1 GB). The physical disk size is measured at the time of disk partitioning.

  The value 1 percent of the physical disk is calculated at the time that the Extensible Firmware Interface System Partition is created and does not change if the disk is extended later (for example, by using RAID).

• Can there be two Extensible Firmware Interface System Partitions on a single disk?

  Such a configuration should not be created and will not be supported.

• What about two Extensible Firmware Interface System Partitions on two different disks?

  Extensible Firmware Interface System Partitions can be replicated for high-availability configurations. Replication must be done manually and the contents must be synchronized manually. Extensible Firmware Interface System Partitions cannot be mirrored.

• What does Microsoft place in the Extensible Firmware Interface System Partition?

  Microsoft places the loader, and other files that are necessary to boot the operating system in the Extensible Firmware Interface System Partition.

• Where should the Extensible Firmware Interface System Partition be placed on the disk?

  The Extensible Firmware Interface System Partition must be first on the disk. While there is no architectural requirement, there are numerous reasons why it is beneficial to place the Extensible Firmware Interface System Partition first. The primary reason for this is that it is impossible to span volumes when the Extensible Firmware Interface System Partition is logically between the two data partitions you are attempting to span.

• What should a computer or device manufacturer place in the Extensible Firmware Interface System Partition?

  The Extensible Firmware Interface System Partition should only include files that are required for booting an operating system, platform tools that run before operating system boot, or files that must be accessed before operating system boot, for example in performing pre-boot system maintenance. Other value-added files or diagnostics that are used while the operating system is running should not be placed in the Extensible Firmware Interface System Partition. It is important to note that the space in the Extensible Firmware Interface System Partition is a limited system resource; its primary purpose is to provide storage for the files that are necessary to boot the operating system.

Where should a computer manufacturer place files such as Platform Diagnostics or other value-added files
